l Compact, pull-proof design

l RJ-45 style interface

l Low insertion loss and low back reflection

l Polarized and color coded (TIA 568-A & ISO 11801)

l UL-Rated plastic housing and boot

l High precision alignment

l Behind the Wall (BTW) style short connector & boot

Descriptions	SM(PC)	SM(UPC)	SM(APC)	MM(PC)
Insertion loss	<0.3dB	≤0.2dB	<0.3dB	<0.3dB
Return loss	≥50dB	≥50dB	≥65dB	≥35dB
Repeatability	≤0.1	≤0.1	≤0.1	≤0.1
Durability	<0.1dB typical change,1000 mating
Interchangeability	≤0.2dB
Vibration	≤0.2dB
Operating Temperature	- 20°C ~ + 70°C
Storage Temperature	- 40°C ~ + 80°C
Cable Diameter	3.0mm, 2.0mm, 0.9mm

TBC		—	LC	/	PC	—	LC	/	PC	/	SM	—	SX	/	2.0	—	3M
0			1		2		3		2		4		5		6		7
0	Brand name
1	Connector#1 LC,SC,FC,ST,E2000,DIN,D4,MU,MTRJ,etc.
2	Lapping Way PC&APC (For MTRJ, F=Female, M=Male)
3	Connector#2 LC,SC,FC,ST,E2000,DIN,D4,MU,MTRJ,Pigtail,etc.
4	Cable Type SM(9/125μm) ,MM(50/125μm & 62.5/125μm)
5	Fiber Number SX(Simplex) or DX(Duplex)
6	Cable Diameter 2.0=Ø2.0mm, 3.0=Ø3.0mm, 0.9=Ø0.9mm, etc.
7	Cable Length 3m(Length in meter)

l Gigabit Ethernet

l Active Device Termination

l Premise Installations

l Telecommunication Networks

l Multimedia
